| Estatus: | CERRADO | | Id# | 18439 | | Ref: | 149981 | | Nombre: | 20 Swing 60 Centers GMC CNC-2060PF NEW CNC LATHE, Siemens 808D control, 3 | | Fabricante: | GMC | | Modelo: | CNC-2060PF | | Año: | ( Nuevo ) | | Localización: | USA | | Precio: | $32,950.00 | | | | |
|---|
| Descripción: | BRAND NEW GMC 20 x 60 High Speed CNC Lathe
w/ Siemens 808D CNC Control
Model: CNC-2060PF
Standard Features:
ISO 9001 certified
Ease-of-use new version SIEMENS 808D CNC control with conversational
programming features, for CNC beginner and easy program and set up.
CNC programmable spindle speeds from 21 to 1,620 rpm.
Large spindle bore 3-1/32, D1-8
Full enclosure safety front and rear guards
One-piece solid cast iron machine base
Heavy Duty guideway width 14
Electrical automatic 4-way turret toolpost
Manual Pulse Generator Metal Handwheel for X & Z
Full ballscrews enclosure
Can use standard flash card for transfer programs and networking FTP
USB port
High speed machining
Popular Ease-of-use Conversational Programming
leads you through programming your part, just fill in
the blanks and check the graphical display. Select from
all canned cycles, such as, profiling, material removing,
roughing and finishing, inside & outside threading, line, arc,
drilling and floating tapping, cut-off, grooving, radius, chamfering
G code and M code programming
CSS-constant surface speeds
CAD/CAM connector & Tools library
Tool length & radius compensation
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system for ballscrews and guideways
Automatic lubrication system in headstock and feed box
One year industrial warranty for parts
Specifications:
Max. swing over bed : 20
Max. length of workpiece: 60
Max. cutting length: 52
Max. swing over cross slide: 8
Max. turning diameter over bed: 12
Width of Bed: 14
Spindle bore: 3-1/32 , D1-8
Taper of spindle center: M.T.# 6
Spindle speeds, CNC programmable: 21-1,620 rpm
Diameter of tailstock quill: 3
Max. travel of tailstock quill (manual): 6
Taper of tailstock quill center: M.T. #5
Auto turret toolpost: 4 positions
Max. tool size for auto turret toolpost: 1 x 1
Max. travel for X axis: 11
Max. travel for Z axis: 55
Main motor: 10 HP, 220V , 3 phase
Coolant pump: 1/8 HP , 220V , 3 phase
Auto lubrication: 1/16 HP , 220V , 3 phase
Net Weight, approx.: 6,650 LBS
Overall Dimensions, LxWxH: 129 x 75 x 86
Standard Equipment:
12 manual 3-jaw chuck with set reversible jaws
Electric automatic turret 4-position toolpost
Handwheel (Manual Pulse Generator) for both X & Z axis movement
Coolant system
Automatic lubrication system
Work light
Slide safety front doors
Full enclosure safety front and rear guards
Tool box and leveling pads
|
|---|
|
|---|
| |
| |
|
|
|
|
|
|
